    多片锯机械 上一条 下一条
    多片锯机械
    点击查看大图
    加入站内收藏
    产品名称:多片锯机械
    公 司 名:邢台市富腾机械厂
    分 类:木工机械
    产品单价:26000
    • 登录后询价,高级会员享受更多权限。
    更新时间:2018/5/1 7:10:14
    所在地点: 河北邢台
    • 电话:0319-7526999
    • 手机:15028885515
    • 传真:0317-7584885
    • 邮箱:174997057@qq.com
    • 地址:河北省邢台市任县环水村工业区
    进入企业网站

    技术参数: 产品型号: YDPJ300B型圆木多片锯 Product name: YDP300B type logs multi chip saw 最大加工长度: 4000mm(连续进料不限长) Maximum machining length: 4000mm(Continuous feeding is not limited to long) 最短加工长度: 800mm The shortest processing length: 800mm 加工圆木直径: 300mm The diameter of sawing logs: 300mm 进料速度: 0-9m(变频器调速) Feed rate: 0-9m(Frequency converter speed regulation) 主电机功率: 30kw/2台 Main motor power: 30kw/2台 外观尺寸: 3600mmX1700mmX1200mm Appearance size: 3600mmX1700mmX1200mm 主轴转速: 3100转/分钟 Spindle speed: 3100转/分钟产品介绍: 本机是一台专业加工规格板材的多片锯机械,采用上滚筒下链条式输送,进料口高度1-30CM之间可以随意调节,加工宽度30CM宽,通过宽度可以订做无限宽,加工规格可以随意调节,最薄加工厚度可以达到8MM,切除的板材尺寸标准,误差在0.3MM之内,表面光滑,无需再刨,节省工序。操作简单,普通工人即可操作,加工效率高,平均每小时出成品2方半左右,一台多片锯可以抵四台传统带锯产量,替企业大量节省人工费用,该多片锯只要用于锯切方料,加工成多片规格。上下轴设计,加工口径大。具有锯路小、锯削表面光滑、高出材率。是加工指接板、细木工板、包装板等最理想的木工机械设备。适用于加工实木规格板,木地板,木托盘,木龙骨,建筑模方,实木拼板、指接板等实木加工企业,已成为众多木材加工企业的必备生产设备!本机是一台专业加工规格板材的多片锯机械,采用上下滚筒式输送,进料口高度1-6CM之间可以随意调节,加工宽度20CM宽,通过宽度可以订做无限宽,加工规格可以随意调节,最薄加工厚度可以达到8MM,切除的板材尺寸标准,误差在0.3MM之内,表面光滑,无需再刨,节省工序。操作简单,普通工人即可操作,加工效率高,平均每小时出成品2方半左右,一台多片锯可以抵四台传统带锯产量,替企业大量节省人工费用,该多片锯只要用于锯切方料,加工成多片规格。上下轴设计,加工口径大。具有锯路小、锯削表面光滑、高出材率。是加工指接板、细木工板、包装板等最理想的木工机械设备。适用于加工实木规格板,木地板,木托盘,木龙骨,建筑模方,实木拼板、指接板等实木加工企业,已成为众多木材加工企业的必备生产设备!  This machine is a professional processing specification plate multi chip saw machine, the drum under the chain conveyor, between the inlet height of 1-30CM can be adjusted freely, working width 30CM wide width can be customized by infinite wide processing specifications can be adjusted, the thinnest thickness can reach 8MM, plate size standard resection and the error is within the range of 0.3MM, the surface is smooth,ordinary workers to operate, the processing efficiency is high, the average per hour 2 half finished,for a large number of enterprises to save labor cost, as long as the multi chip saw used for cutting materials, processed into multiple specifications. The upper and lower shaft design, machining large diameter. With a small sawing, sawing surface smooth, high rate of material. It is the most ideal woodworking machinery, such as the processing of the connecting plate, the fine wood board and the packaging board. Suitable for processing wood tiles, wood floors, wooden pallets, wooden keel, construction formwork, finger board and other wood processing enterprises, wood board, has become the necessary equipment for many wood processing enterprises! This machine is a professional processing specification plate multi chip saw machine, the upper and lower roller conveyor, between the inlet height of 1-6CM can be adjusted freely, working width 20CM wide width can be customized by infinite wide processing specifications can be adjusted, the thinnest thickness machining can reach 8MM, plate size standard resection and the error is within the range of 0.3MM, the surface is smooth, no plane, save the process. Simple, ordinary workers to operate, the processing efficiency is high, the average per hour 2 half finished, a multi chip saw can reach four Taiwan traditional band production, for a large number of enterprises to save labor cost, as long as the multi chip saw used for cutting materials, processed into multiple specifications. The upper and lower shaft design, machining large diameter. With a small sawing, sawing surface smooth, high rate of material. It is the most ideal woodworking machinery, such as the processing of the connecting plate, the fine wood board and the packaging board. Suitable for processing wood tiles, wood floors, wooden pallets, wooden keel, construction formwork, finger board and other wood processing enterprises, wood board, has become the necessary equipment for many wood processing enterprises!
